Cisco PA-4E1G/75
4-Port E1 G.703 Serial Port Adapter (75ohm/Unbalanced)
In Stock
US $190.00
Product Highlights
Family
Modules
Brand
Cisco
Warranty
Lifetime (see details)
Availability
Usually Ships within 2-3 Days
Twitter Reddit Facebook
Information
The Cisco 4-Port E1 G.703 Serial Port Adapter (PA-4E1G) provides up to four E1 synchronous serial interfaces, which are compatible with and specified by G.703. The port adapter network interfaces provide a connection between standard serial interfaces such as V.35 to telephone lines or post, telephone, and telegraph (PTT) networks. Each port adapter interface operates in full-duplex mode at E1 (2.048 Mbps) speed.
Specifications
Dimensions
1.0" Height x 6.6" Width x 7.0" Depth
Product Name
4-Port E1 G.703 Serial Port Adapter
Product Type
Port Adapter
Compatibility
- Cisco 7200 Series NPE-225 Network Processing Engine (NPE-225)
- Cisco 7200 Series NPE 400
- Cisco 7200 Series NPE-G1 Cisco 7304:
- Cisco 7304 Internet Router NSE-100 Forwarding Engine (NSE-100)
- NPE-G100
- Cisco 7301: NPE-G1
- Cisco 7500: Versatile Interface Processor (VIP)
- Cisco 7600: FlexWAN and Enhanced FlexWAN
Shipping Weight
1.75 lb
Interfaces/Ports
4 x E1
Application/Usage
Data Networking
Connectivity Media
75-ohm Coaxial
Data Transfer Rate
2.05 Mbps E1
Interfaces Details
4 x DB-15 E1
Additional Information
- Supports 4-bit cyclic redundancy check (CRC4) to provide and ensure data integrity
- Supports point-to-point connections to supported platforms
- Provides for local and remote loopback testing services
- Allows you to fractionalize a data stream into a single channel from 64 to 1984 kbps
- Provides framed and unframed service access, E1 (2.048 Mbps) line speeds over unbalanced 75-ohm cable
